John Deere 9560RT Tests


John Deere 9560RT tractor photo
2012 - 2014
9R/RT Series
Agricultural Crawler tractor
Series map:
9510RT
9560RT
510.0hp
560.0hp
OCED Tractor Test 2045
9560RT fuel use from test 836
OCED Tractor Test 2045
Diesel 18-speed crawler
October 12 - 23, 2012
Link: OCED Tractor Test 2045 file
PTO performance
Max power354.45 hp
264.3 kW
Fuel use20.4 gal/hour
77.2 l/hour
Power at rated engine speed309.98 hp
231.2 kW
Fuel use20.5 gal/hour
77.6 l/hour
Power at rated PTO speed346.35 hp
258.3 kW
Fuel use20.8 gal/hour
78.7 l/hour
Drawbar performance
Max power433.29 hp
323.1 kW
Fuel use28.2 gal/hour
106.7 l/hour
Gear 7 used for power test.
Max pull48255 lbs
21888 kg
Gear 1 used for pull test.
