John Deere 9510RT Tests


John Deere 9510RT tractor photo
2012 - 2014
9R/RT Series
Agricultural Crawler tractor
Series map:
9460RT
9510RT
9560RT
460.0hp
510.0hp
560.0hp
OCED Tractor Test 2043
9510RT fuel use from test 834
OCED Tractor Test 2043
Diesel 18-speed crawler
October 2 - 16, 2012
Link: OCED Tractor Test 2043 file
PTO performance
Max power358.38 hp
267.2 kW
Fuel use20.6 gal/hour
78.0 l/hour
Power at rated engine speed313.42 hp
233.7 kW
Fuel use20.8 gal/hour
78.7 l/hour
Power at rated PTO speed353.42 hp
263.5 kW
Fuel use21.3 gal/hour
80.6 l/hour
Drawbar performance
Max power391.80 hp
292.2 kW
Fuel use26.0 gal/hour
98.4 l/hour
Gear 7 used for power test.
Max pull48210 lbs
21868 kg
Gear 1 used for pull test.
