J.I. Case 18-32
| | 1924 - 1927 |
| Crossmotor Series | | Standard-tread tractor |
|
Series map:
18-32
25-45
35.6hp*
50.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | J.I. Case
|
| Standard-tread tractor |
| Built in Racine, Wisconsin, USA |
| J.I. Case 18-32 Power |
| Drawbar (claimed) | 18 hp
13.4 kW
|
| Belt (claimed) | 32 hp
23.9 kW
|
| Plows | 3
|
| Drawbar (tested) | 24.52 hp
18.3 kW
|
| Belt (tested) | 36.73 hp
27.4 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Steering | manual
|
| Open operator station. |
| Power Take-off (PTO) |
| Rear PTO Type | 540
|
| 18-32 Serial Number Location |
 |
| Left rear fender. |
| Belt Pulley |
| Diameter | 16 inches
40 cm
|
| Width | 7.5 inches
19 cm
|
| RPM | 1000
|
| Speed | 4,180 ft/min
1274.06 meters/min
|
