CaseIH Maxxum 115


CaseIH Maxxum 115 tractor photo
2007 - 2025
Model year
Maxxum Series
Row-Crop tractor
Series map:
Maxxum 110
Maxxum 115
Maxxum 120
110.0hp
116.0hp
121.0hp
Production
ManufacturerCaseIH
Row-Crop tractor
Original price was $87,550 in 2013
CaseIH Maxxum 115 Transmissions
24-speed two-speed power shift
17-speed partial power shift
Transmission details ...
CaseIH Maxxum 115 Power
Engine (gross)116 hp
86.5 kW
Engine (max)127 hp
94.7 kW
PTO (claimed)95 hp
70.8 kW
Drawbar (tested)87.3 hp
65.1 kW
PTO (tested)113.0 hp
84.3 kW
Performance test details ...
Mechanical
Four-wheel drive
Differential lockstandard, optional wet plate lock
Steeringhydrostatic power
Hydraulic wet disc brakes
Cab standard. Optional suspended cab.
Capacity
Fuel60 gal
227.1 L
Exhaust fluid (DEF)9.7 gal
36.7 L
Hydraulic system19.5 gal
73.8 L
Hydraulics
Typeopen center
 pressure flow compensating (optional)
Capacity19.5 gal
73.8 L
Rear valves2 to 4 (mechanical)
 3 or 4 (electrohydraulic)
Mid valves0, 2 or 3
Pump flow18 gpm
68.1 lpm
 26.5 gpm (PFC)
100.3 lpm
Total flow29.2 gpm
110.5 lpm
 43.6 gpm (PFC)
165.0 lpm
Steering flow10.5 gpm
39.7 lpm
 17.1 gpm (PFC)
64.7 lpm
Tractor hitch
Rear TypeII
 IIIN/II (optional)
Rear lift6200 lbs
2812 kg
 6900 lbs (optional)
3129 kg
 7700 lbs (optional)
3492 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
Wheelbase103.4 inches
262 cm
 105.5 inches (suspended front axle)
267 cm
Weight12500 lbs
5670 kg
Full dimensions and tires ...
Maxxum 115 Serial Number Location
CaseIH Maxxum 115 serial number location
Serial number tag on the left side of the radiator support.
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 150 (optional)
Batteries2
Battery CCA800
Battery volts12
References
Maxxum 115 references literature
Maxxum Tractor Specifications published in 2011, by CaseIH
Maxxum Series Tractors published in 2012, by CaseIH
