Bolens G212 G2102
|
|
| Production | |
| Distributor | Bolens |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Bolens G212 Engine | |
| Isuzu 1.2L 3-cyl diesel | |
| Fuel tank | 6.1 gal 23.1 L |
 Engine details ... | |
| Bolens G212 Transmission | |
| 12-speed gear | |
 Transmission details ... |
| Bolens G212 Power | |
| Engine | 21 hp 15.7 kW |
| Mechanical | |
| Two-wheel drive | |
| Differential lock | mechanical rear |
| Manual steering | |
| Mechanical internal expanding brakes | |
| Open operator station. | |
| Photos | |
 | |
 Bolens G212 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 4.8 gpm 18.2 lpm |
| Tractor hitch | |
| Rear Type | 0 |
| Control | position control |
| Rear lift | 1400 lbs 635 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@2108 |
| 1000@2444 | |
| Dimensions & Tires | |
| Wheelbase | 59 inches 149 cm |
| Weight | 1588 lbs 720 kg |
| Front tire | 4.00-12 |
| Rear tire | 12.4-16 |
 Full dimensions and tires ... | |
| Bolens G212 attachments | |
| 60" mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| G212 Serial Numbers | |
| Location: | Serial number plate on the left side of the main tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 35 |
| Battery CCA | 305 |
| Battery volts | 12 |
| Battery AH | 45 |
| References | |
 | |
| High Performance published in 1987, by Bolens | |
| Bolens Diesel published in 1983 |
