Bolens G152



Bolens G152 tractor photo
1978 - 1991
Model year
Sub-Compact Utility tractor
Iseki built
Series map:
G152
G154
15.0hp
15.0hp
Production
DistributorBolens
ManufacturerIseki
Sub-Compact Utility tractor
Variants
G1522WD gear drive
H15022WD hydrostatic
G1544WD gear drive
TX2140similar Iseki model
Bolens G152 Engine
Mitsubishi 0.8L 3-cyl diesel
Fuel tank3.17 gal
12.0 L
Engine details ...
Bolens G152 Transmission
6-speed unsynchronized gear
Transmission details ...
Bolens G152 Power
Engine15 hp
11.2 kW
Mechanical
Two-wheel drive
Differential lockmechanical standard
Manual steering
Mechanical internal expanding brakes
Open operator station. Two-post ROPS (#17368) optional. Soft-side cab (#19705) optional
Photos
Bolens G152
Bolens G152 photos...
Hydraulics
Typeopen center
Pressure1850 psi
127.6 bar
Pump flow3 gpm
11.4 lpm
Tractor hitch
Rear TypeI/0
Controlposition control
Rear lift830 lbs
376 kg
Power Take-off (PTO)
Rear PTOtransmission
Rear PTO Type454/724/1185
Engine RPM454@2700
 724@2700
 1185@2700
Dimensions & Tires
Wheelbase50.4 inches
128 cm
Weight1080 lbs
489 kg
Front tire4.50x10
Rear tire8-16
Full dimensions and tires ...
Bolens G152 attachments
48" mid-mount mower deck
snowblower
blade
front-end loader
backhoe
Attachment details ...
G152 Serial Number Location
Bolens G152 serial number location
Serial number plate near gear shift.
Electrical
Groundnegative
Charging systemalternator
Charging amps35
Battery CCA305
Battery volts12
References
G152 references literature
High Performance published in 1987, by Bolens
Lawn & Garden published in 1988, by Bolens*
Lawn and Garden Power Products published in 1989, by Bolens
Equipment Seminar published in 1982
Bolens Diesel published in 1983
*Publication contains known errors.
