John Deere 2955 High Clearance
|
|
| Production | |
| Manufacturer | John Deere |
| High-Clearance tractor | |
| Variants | |
| 2955 | utility |
| John Deere 2955 High Clearance Engine | |
| John Deere 5.9L 6-cyl diesel | |
| Fuel tank | 32 gal 121.1 L |
 Engine details ... | |
| John Deere 2955 High Clearance Transmission | |
| 12-speed partially synchronized | |
 Transmission details ... |
| John Deere 2955 High Clearance Power |
| Mechanical | |
| Four-wheel drive | |
| Steering | power |
| Two-post ROPS. Canopy optional. Four-post ROPS and Sound-Gard cab available. | |
| Photos | |
| No photos of the John Deere 2955 High Clearance are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Pump flow | 21 gpm 79.5 lpm |
| Tractor hitch | |
| Rear Type | 2 |
| Rear lift | 5,235 lbs 2374 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540/100 |
| Dimensions & Tires | |
| Wheelbase | 101.7 inches 258 cm |
| Front tire | 13.6-38 |
| Rear tire | 13.6-46 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging volts | 55 |
| Batteries | 2 |
| Battery CCA | 610 |
| Battery volts | 12 |
| References | |
 | |
| Special Power published in 1990, by John Deere | |
| The 1991 Long Green Line Agricultural Equipment Review published by John Deere |
