John Deere 7215R Transmission


John Deere 7215R tractor photo
2011 - 2013
7R Series
Row-Crop tractor
Series map:
7200R
7215R
7230R
200.0hp
215.0hp
230.0hp
Transmission options
16-speed partial power shift
20-speed partial power shift
20-speed power shift
infinitely variable transmission
Transmission
TransmissionJohn Deere PowrQuad Plus
Typepartial power shift
Gears16 forward and reverse
Four gears (1-4) in four ranges (A-D) with left-hand reverser lever. Push-button power shifting between gears. Synchronized shifting between ranges using the foot clutch, or de-clutch button. Power shuttle shifting between forward and reverse.
Speeds
With Group 47 rear tires.
7215R PowrQuad Plus partial power shift speeds
Transmission
TransmissionJohn Deere AutoQuad Plus
Typepartial power shift
Gears20 forward and reverse
The AutoQuad transmission adds automatic shifting to the PowrQuad. The tractor will automatically shift between two or all four gears within a range to maintain load.
Speeds
With Group 47 rear tires.
7215R AutoQuad Plus partial power shift speeds
Transmission
TransmissionJohn Deere CommandQuad Eco
Typepower shift
Gears20 forward and reverse
The CommandQuad transmission uses a single shift control lever, with automatic gear and range shifting. CommandQuad available with 40 kph or 50 kph top speeds.
Speeds
With Group 47 rear tires. 40 kph transmission has lower speeds in E3 and E4.
7215R CommandQuad Eco power shift speeds
Transmission
TransmissionJohn Deere AutoPowr IVT
Typeinfinitely variable transmission
Gearsinfinite forward and reverse
