John Deere 730


John Deere 730 tractor photo
1961 - 1971
Row-Crop tractor
Series map:
445
730
26.8kw
48.9kw*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Rosario, Argentina
The John Deere model 730, originally built in Waterloo, was also exported to Argentina and assembled at Deere's factory in Rosario. When two-cylinder production ended at Waterloo the tooling for the 730 was moved to Argentina. Production continued until 1971. Argentine model 730s were built in row-crop, standard, and high-crop variants. The paint scheme and hood medallion were different than US-built 730s.
John Deere 730 Engines
John Deere 5.9L 2-cyl gasoline
John Deere 6.2L 2-cyl diesel
Fuel tank26.5 gal (gasoline)
100.3 L
 20 gal (diesel)
75.7 L
Engine details ...
John Deere 730 Power
Drawbar (claimed)53 hp
39.5 kW
PTO (claimed)59 hp
44.0 kW
Plows5
Mechanical
Two-wheel drive
Steeringmanual
Differential mechanical drum brakes
Open operator station. Optional Float-Ride seat.
Hydraulics
Typeopen center
Valves1 or 2
Tractor hitch
Rear TypeII (optional)
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
Dimensions & Tires
Wheelbase93.7 inches
237 cm
Weight6790 to 7861 pounds
Front tire6.00-16
Rear tire13.6-38
Full dimensions and tires ...
Belt Pulley
Diameter12.8 inches
32 cm
Width7.4 inches
18 cm
RPM1,125
Speed3,790 ft/min
1155.19 meters/min
Electrical
Groundpositive
Charging systemgenerator
Batteries2
 4 (diesel)
Battery volts6
References
730 references literature
The John Deere 30 Series by J.R. Hobbs
