Tractors > John Deere > 7330 Premium High-Crop

John Deere 7330 Premium High-Crop



John Deere 7330 Premium High-Crop tractor photo
2007 - 2012
7030 Small-Frame Series
High-Clearance tractor
Series map:
7330 Premium High-Crop
155.0hp
Production
ManufacturerJohn Deere
High-Clearance tractor
Built in Waterloo, Iowa, USA
Original price$121,658 (2011)
Variants
7330base tractor
7330 Premiumdeluxe tractor
7330 Premium High-Crophigh-clearance
John Deere 7330 Premium High-Crop Engine
John Deere 6.8L 6-cyl diesel
Fuel tank66 gal
249.8 L
 83 gal (optional)
314.2 L
Engine details ...
John Deere 7330 Premium High-Crop Transmissions
16-speed
20-speed
32-speed
Transmission details ...
John Deere 7330 Premium High-Crop Power
Engine (gross)155 hp
115.6 kW
PTO (claimed)127 hp
94.7 kW
Mechanical
Four-wheel drive
Steeringhydrostatic power
Hydraulic wet disc brakes
ComfortGard Premium cab standard.
Photos
No photos of the John Deere 7330 Premium High-Crop are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure and flow compensated (PFC)
Pressure2900 psi
200.0 bar
Rear valves2 to 4
Pump flow29 gpm
109.8 lpm
Tractor hitch
Rear TypeII
 IIIN/II (optional)
Controlelectronic lower link
Rear lift (at 24"/610mm)8,800 lbs (II)
3991 kg
 9,950 lbs (II optional)
4513 kg
 8,200 lbs (3N/2)
3719 kg
 9,400 lbs (3N/2 optional)
4263 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
 540/540E/1000 (optional)
Engine RPM540@1987
 1000@1995
Front PTO Type1000
Dimensions & Tires
Wheelbase109 inches
276 cm
Weight10800 to 13360 pounds
Front tire320/90R46
Rear tire320/90R46
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging volts14
Battery volts12
References
7330 Premium High-Crop references literature
6030 and 7030 Series Tractors published in 2007, by John Deere
Specialty Tractors published in 2008, by John Deere
Specialty Tractors published in 2012, by John Deere
