John Deere 6200



John Deere 6200 tractor photo
1992 - 1997
Series map:
6100
6200
6300
55.9kw
62.6kw
67.1kw
Production
ManufacturerJohn Deere
Built in Mannheim, Baden-Württemberg, Germany
Variants
6200SEeconomy model
John Deere 6200 Engine
John Deere 3.9L 4-cyl diesel
Fuel tank42.3 gal
160.1 L
Engine details ...
John Deere 6200 Transmissions
12-speed fully synchronized
15-speed fully synchronized
16-speed partial power shift
20-speed partial power shift
Transmission details ...
John Deere 6200 Power
Engine84 hp
62.6 kW
Mechanical
Two- or four-wheel drive
Steeringhydrostatic power
Wet disc brakes
Cab standard.
Photos
No photos of the John Deere 6200 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2900 psi
200.0 bar
Total flow15.85 gpm
60.0 lpm
Tractor hitch
Rear TypeII
Rear lift9396 lbs*Maximum force at top end of lift range
4262 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
 540/540E/1000 OptOptional
Engine RPM540@2017
 540E@1684
 1000@2208
Front PTOindependent
Front PTO Type1000
Dimensions & Tires
Wheelbase94.5 inches
240 cm
Weight8300 to 8710 pounds
Front tire10.00-16
Rear tire16.9R34 (2WD)
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps110
Battery volts12
Battery AH154
References
6200 references literature
Flexibla och Produktiva published in 1995, by John Deere
