Tractors > John Deere > 3200

John Deere 3200



John Deere 3200 tractor photo
1995 - 1998
Utility tractor
Renault built
Series map:
3100
3200
3300
41.0kw
48.5kw
55.9kw
Production
DistributorJohn Deere
ManufacturerRenault
Utility tractor
Built in Le Mans, France
John Deere 3200 Engine
John Deere 3.9L 4-cyl diesel
Fuel tank30.4 gal
115.1 L
 38.3 galOptOptional
145.0 L
Engine details ...
John Deere 3200 Transmissions
10-speed synchronized
20-speed synchronized
20-speed two-speed power shift
Transmission details ...
John Deere 3200 Power
Engine (net)65 hp
48.5 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with heater. Optional deluxe X Cab.
Photos
No photos of the John Deere 3200 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2611 psi
180.0 bar
Pump flow13.7 gpm
51.9 lpm
Steering flow7 gpm
26.5 lpm
Tractor hitch
Rear TypeII
Controllower-link draft sensing
Rear lift6317 lbs
2865 kg
 8430 lbsOptOptional
3823 kg
Power Take-off (PTO)
Rear PTOindependent
3200 Clutchmechanical
3200X Clutchhydraulic
Rear PTO Type540/540E
 540 OptOptional
 540/1000 OptOptional
Dimensions & Tires
Weight7121 lbs
3230 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps65
Battery volts12
Battery AH105
References
3200 references literature
New John Deere 3000 Series Tractors published in 1994
