CaseIH Puma 185
|
|
| Production | |
| Manufacturer | CaseIH |
| Row-Crop tractor | |
| Built in Basildon, England | |
| CaseIH Puma 185 Engine | |
| FPT 6.7L 6-cyl diesel | |
 Engine details ... |
| CaseIH Puma 185 Transmissions | |
| 18-speed full power shift | |
| 19-speed full power shift | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| CaseIH Puma 185 Power | |
| Engine (gross) | 185 hp 138.0 kW |
| Engine (max) | 234 hp 174.5 kW |
| PTO (claimed) | 155 hp 115.6 kW |
| PTO (tested) | 187.5 hp 139.8 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Cab standard. Optional cab suspension. | |
| Photos | |
 | |
 CaseIH Puma 185 photos... | |
| Capacity | |
| Fuel | 104 gal 393.6 L |
| Exhaust fluid (DEF) | 13.2 gal 50.0 L |
| Hydraulic system | 22 gal 83.3 L |
| Hydraulics | |
| Type | closed center pressure flow compensating (PFC) |
| Capacity | 22 gal 83.3 L |
| Rear valves | 3 to 4 (mechanical) |
| 3 to 5 (electronic) | |
| Pump flow | 32 gpm (powershift) 121.1 lpm |
| 35 gpm (CVT/opt-PS) 132.5 lpm | |
| 40 gpm (CVT opt) 151.4 lpm | |
| Total flow | 49 gpm (powershift) 185.5 lpm |
| 52 gpm (CVT/opt-PS) 196.8 lpm | |
| 57 gpm (CVT opt) 215.7 lpm | |
| Steering flow | 17 gpm 64.3 lpm |
| Tractor hitch | |
| Rear Type | 2/3N |
| Rear lift | 10,200 lbs 4626 kg |
| 13,400 lbs (optional) 6078 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.75) |
| 1000 (1.75) | |
| 1000/1000E | |
| Dimensions & Tires | |
| Wheelbase | 113.6 inches 288 cm |
| Weight | 18135 lbs 8226 kg |
 Full dimensions and tires ... | |
| CaseIH Puma 185 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 150 |
| 200 OptOptional | |
| Battery CCA | 1300 |
| Battery volts | 12 |
| References | |
 | |
| Puma Series Tractors published in 2010, by CaseIH | |
| Puma Series Tractors published in 2011, by CaseIH |
