John Deere 8360RT
| | 2011 - 2013 |
| 8R Series | | Agricultural Crawler tractor |
|
Series map:
8335RT
8360RT
335.0hp
360.0hp
| Production |
| Manufacturer | John Deere
|
| Agricultural Crawler tractor |
| Built in Waterloo, Iowa, USA |
| The John Deere 8360RT was re-tested at Nebraska (Test 2000A) to reflect the new three-point lift capacity for the 2012 model year. |
| John Deere 8360RT Power |
| Engine (gross) | 360 hp
268.5 kW
|
| Engine (max) | 396 hp
295.3 kW
|
| PTO (claimed) | 288 hp
214.8 kW
|
| Drawbar (tested) | 256.60 hp
191.3 kW
|
| PTO (tested) | 339.86 hp
253.4 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | electro-hydraulic power
|
| CommandView II cab standard with heat and air-conditioning. |
| Capacity |
| Hydraulic system | 68.3 gal
258.5 L
|
| Hydraulics |
| Type | closed center pressure-flow compensated
|
| Capacity | 68.3 gal
258.5 L
|
| Pressure | 2900 psi
200.0 bar
|
| Rear valves | 3 to 5
|
| Pump flow | 35 gpm
132.5 lpm
|
| Total flow | 60 gpm
227.1 lpm
|
| Tractor hitch |
| Rear Type | 4N/3
|
| Rear lift (at 24"/610mm) | 19,300 lbs (2011)
8754 kg
|
| | 20,000 lbs (2012-2013)
9072 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1-3/4)
|
| 8360RT Serial Number Location |
 |
| Serial number on the right side of main tractor frame, below the engine. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 200
|
| Batteries | 2
|
| Battery CCA | 925
|
| Battery volts | 12
|
