Ford 4610SU Tests
|
|
| Tractor Tests | |
| NTTL 1426: diesel 8x2 2WD | |
| NTTL 1427: diesel 8x4 2WD |
| Nebraska Tractor Test 1426 | |||
| |||
| Nebraska Tractor Test 1426 | |
| Diesel 8x2 2WD March 16 - April 1, 1982 Link: Nebraska Tractor Test 1426 file | |
| PTO performance | |
| Power at rated engine speed | 52.52 hp 39.2 kW |
| Fuel use | 3.3 gal/hour 12.5 l/hour |
| Power at rated PTO speed | 46.72 hp 34.8 kW |
| Fuel use | 1.0 gal/hour 3.8 l/hour |
| Drawbar performance | |
| Max power | 44.28 hp 33.0 kW |
| Fuel use | 3.2 gal/hour 12.1 l/hour |
| Gear 5 used for power test. | |
| Max pull | 6402 lbs 2903 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 1427 | |||
| |||
| Nebraska Tractor Test 1427 | |
| Diesel 8x4 2WD April 24 - May 15, 1982 Link: Nebraska Tractor Test 1427 file | |
| PTO performance | |
| Power at rated engine speed | 52.32 hp 39.0 kW |
| Fuel use | 3.3 gal/hour 12.5 l/hour |
| Power at rated PTO speed | 47.30 hp 35.3 kW |
| Fuel use | 2.8 gal/hour 10.6 l/hour |
| Drawbar performance | |
| Max power | 43.17 hp 32.2 kW |
| Fuel use | 3.2 gal/hour 12.1 l/hour |
| Gear 5 used for power test. | |
| Max pull | 6,534 lbs 2963 kg |
| Gear 2 used for pull test. | |
