John Deere 5090GV


No photo available
2009 - 2013
5G Series
Orchard/Vineyard tractor
Agritalia built
Series map:
5080GV
5090GV
5100GV
59.7kw
67.1kw
74.6kw
Production
DistributorJohn Deere
ManufacturerAgritalia
Orchard/Vineyard tractor
Built in Rovigo, Italy
Variants
5090Gutility
5090GHhigh-crop
5090GForchard
5090GVvineyard
John Deere 5090GV Engine
John Deere 4.5L 4-cyl diesel
Fuel tank40.2 gal
152.2 L
Engine details ...
John Deere 5090GV Power
Engine90 hp
67.1 kW
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringhydrostatic power
Wet disc brakes
ROPS (2-post); Cab optional.
Photos
No photos of the John Deere 5090GV are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2700 psi
186.2 bar
Pump flow11.9 gpm
45.0 lpm
 15.6 gpm (optional)
59.0 lpm
Total flow18.9 gpm
71.5 lpm
 22.3 gpm (optional)
84.4 lpm
 27.6 gpm (optional)
104.5 lpm
Steering flow6.5 gpm
24.6 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Rear lift5,845 lbs
2651 kg
Power Take-off (PTO)
Rear PTO Type540/540E/ground
 540/1000/ground
Dimensions & Tires
Wheelbase85 inches
215 cm
Weight5776 to 6460 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
 95 (cab)
Battery volts12
Battery AH100
References
5090GV references literature
5 Series Speciality tractors published in 2009, by John Deere
