John Deere 5090GH


John Deere 5090GH tractor photo
2009 - 2013
5G Series
High-Clearance tractor
Agritalia built
Production
DistributorJohn Deere
ManufacturerAgritalia
High-Clearance tractor
Built in Rovigo, Italy
Variants
5090Gutility
5090GHhigh-crop
5090GForchard
5090GVvineyard
John Deere 5090GH Engine
John Deere 4.5L 4-cyl diesel
Fuel tank25.4 gal
96.1 L
Engine details ...
John Deere 5090GH Power
Engine90 hp
67.1 kW
Mechanical
Two-wheel drive
Steeringhydrostatic power
Wet disc brakes
ROPS (4-post). Cab optional.
Photos
No photos of the John Deere 5090GH are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2700 psi
186.2 bar
Pump flow11.9 gpm
45.0 lpm
 15.6 gpm (optional)
59.0 lpm
Steering flow6.5 gpm
24.6 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Rear lift5,845 lbs
2651 kg
Power Take-off (PTO)
Rear PTO Type540/540E/ground
 540/1000/ground
Dimensions & Tires
Wheelbase86 inches (2WD)
218 cm
 87 inches (4WD)
220 cm
Weight7231 to 7496 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
 95 (cab)
Battery volts12
Battery AH100
References
5090GH references literature
5 Series Speciality tractors published in 2009, by John Deere
