John Deere 5080GF



John Deere 5080GF tractor photo
2009 - 2013
5G Series
Orchard/Vineyard tractor
Agritalia built
Series map:
5080GF
5090GF
59.7kw
67.1kw
Production
DistributorJohn Deere
ManufacturerAgritalia
Orchard/Vineyard tractor
Built in Rovigo, Italy
Variants
5080Gutility
5080GForchard
5080GVvineyard
John Deere 5080GF Engine
John Deere 4.5L 4-cyl diesel
Fuel tank40.2 gal
152.2 L
Engine details ...
John Deere 5080GF Transmissions
12-speed
24-speed
Transmission details ...
John Deere 5080GF Power
Engine80 hp
59.7 kW
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Steeringhydrostatic power
Wet disc brakes
ROPS (2-post); Cab optional.
Photos
No photos of the John Deere 5080GF are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2700 psi
186.2 bar
Pump flow11.9 gpm
45.0 lpm
 15.6 gpm (optional)
59.0 lpm
Total flow18.9 gpm
71.5 lpm
 22.3 gpm (optional)
84.4 lpm
 27.6 gpm (optional)
104.5 lpm
Steering flow6.5 gpm
24.6 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Rear lift5,845 lbs
2651 kg
Power Take-off (PTO)
Rear PTO Type540/540E/ground
 540/1000/ground
Dimensions & Tires
Wheelbase85 inches
215 cm
Weight5776 to 6460 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
 95 (cab)
Battery volts12
Battery AH100
References
5080GF references literature
5 Series Speciality tractors published in 2009, by John Deere
