Tractors > John Deere > 5080G

John Deere 5080G



John Deere 5080G tractor photo
2009 - 2013
5G Series
Utility tractor
Agritalia built
Series map:
5080G
5090G
59.7kw
67.1kw
Production
DistributorJohn Deere
ManufacturerAgritalia
Utility tractor
Built in Rovigo, Italy
Variants
5080Gutility
5080GForchard
5080GVvineyard
John Deere 5080G Engine
John Deere 4.5L 4-cyl diesel
Fuel tank25.4 gal
96.1 L
Engine details ...
John Deere 5080G Transmissions
12-speed
24-speed
Transmission details ...
John Deere 5080G Power
Engine80 hp
59.7 kW
Mechanical
Two- or four-wheel drive
Steeringhydrostatic power
Wet disc brakes
ROPS (2- or 4-post). Cab optional.
Photos
No photos of the John Deere 5080G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2700 psi
186.2 bar
Pump flow11.9 gpm
45.0 lpm
 15.6 gpmOptOptional
59.0 lpm
Steering flow6.5 gpm
24.6 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Rear lift5,845 lbs
2651 kg
Power Take-off (PTO)
Rear PTO Type540/540E/ground
 540/1000/ground
Dimensions & Tires
Wheelbase86 inches
218 cm
Weight6724 to 7055 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
 95 (cab)
Battery volts12
Battery AH100
References
5080G references literature
5 Series published in 2009, by John Deere
