John Deere 5100M


John Deere 5100M tractor photo
2009 - 2013
5M Series
Utility tractor
Series map:
5090M
5100M
67.1kw
74.6kw
Production
ManufacturerJohn Deere
Utility tractor
John Deere 5100M Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 5100M Transmissions
32-speed two-speed power shift
16-speed power shuttle
16-speed partially synchronized
Transmission details ...
John Deere 5100M Power
Engine (gross)100 hp
74.6 kW
Engine (max)102 hp
76.1 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic rear
Steeringhydrostatic power
Wet disc brakes
Trailer brakeshydraulic *Optional.
 pneumatic *Optional.
Cab standard. Optional air-conditioning.
Photos
No photos of the John Deere 5100M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2901 psi
200.0 bar
Rear valves3 *Maximum
Mid valves2 *Maximum
Pump flow19.55 gpm
74.0 lpm
 24.8 gpm*Optional.
93.9 lpm
Tractor hitch
Rear TypeII
Controllower-link draft control *Mechanical standard, electronic optional.
Rear lift (at ends)8093 lbs
3670 kg
Front HitchII OptOptional
Front lift (at ends)6519 lbs
2957 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet discs
Rear PTO Type540/540E/ground
 540/540E
 540/540E/1000
Engine RPM540@2100
 540E@1645
 1000@2100
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet discs
Front PTO Type1000
Engine RPM1000@21080
Dimensions & Tires
Wheelbase88.6 inches
225 cm
Weight8157 lbs
3700 kg
Front tire13.6R24
Rear tire16.9R34
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5100M references literature
5 Series published in 2009, by John Deere
