John Deere 5080R


John Deere 5080R tractor photo
2009 - 2016
5R Series
Utility tractor
Series map:
5080R
5090R
59.7kw
67.1kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 5080R Engine
John Deere 4.5L 4-cyl diesel
Fuel tank34.3 gal
129.8 L
 39.6 gal (optional)
149.9 L
Engine details ...
John Deere 5080R Transmissions
16-speed four-speed power shuft
32-speed creeper
Transmission details ...
John Deere 5080R Power
Engine80 hp
59.7 kW
PTO (claimed)67 hp
50.0 kW
Mechanical
Four-wheel drive
Steeringhydrostatic power
Wet disc brakes
Cab standard. Optional A/C.
Photos
No photos of the John Deere 5080R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeload sensing pressure compensated
Pressure2900 psi
200.0 bar
Valvesup to 3
Total flow14.8 gpm
56.0 lpm
 17.2 gpm (optional)
65.1 lpm
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/540E
 540/540E/1000
Engine RPM540@2097
 540E@1700
 1000@2074
Front PTO Type1000
Dimensions & Tires
Wheelbase88.6 inches
225 cm
Weight8,157 lbs
3700 kg
Front tire13.6R24
Rear tire16.9R34
Full dimensions and tires ...
5080R Serial Numbers
Location:Right side of tractor frame, above the front axle.
References
5080R references literature
5 Series published in 2009, by John Deere
5 Series Speciality tractors published in 2009, by John Deere
