John Deere 5620



John Deere 5620 tractor photo
2003 - 2008
Utility tractor
Series map:
5620
5720
53.7kw
59.7kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 5620 Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 5620 Transmissions
16-speed
32-speed
Transmission details ...
John Deere 5620 Power
Engine72 hp
53.7 kW
PTO (claimed)61 hp
45.5 kW
Mechanical
Four-wheel drive
Steeringhydrostatic power
Wet disc brakes
Cab standard. Optional A/C.
Photos
No photos of the John Deere 5620 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel30.1 gal
113.9 L
 34.6 gal (optional)
131.0 L
Hydraulic system13.75 gal
52.0 L
Front axle4.8 qts
4.5 L
Front hubs0.7 qts
0.7 L
Hydraulics
Typeload sensing pressure compensated
Capacity13.75 gal
52.0 L
Pressure2900 psi
200.0 bar
Valvesup to 3
Total flow14.8 gpm
56.0 lpm
 17.2 gpm (optional)
65.1 lpm
Oil type
-10oF [-23oC]↑ : HY-GARD
-40o↔86oF [-40o↔30oC]   : Low Viscosity HY-GARD
-10oF [-23oC]↑ : JDM J20C
-40o↔86oF [-40o↔30oC]   : JDM J20D
Tractor hitch
Rear TypeII
Rear lift (at ends)8,319 lbs
3773 kg
Front Hitchoptional
Front lift6,519 lbs
2957 kg
Power Take-off (PTO)
Rear PTO Type540/540E
 540/540E/1000
Front PTOoptional
Front PTO Type1000
Dimensions & Tires
Wheelbase88.6 inches
225 cm
Weight7,826 lbs
3549 kg
Front tire12.4R24
Rear tire16.9R30
Full dimensions and tires ...
John Deere 5620 attachments
front-end loader
Attachment details ...
5620 Serial Numbers
Location:Main frame on right side
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 115 (optional)
Battery volts12
Battery AH110
 154 (optional)
References
5620 references literature
5020 Series published in 2003, by John Deere
