Tractors > John Deere > 6110L

John Deere 6110L



John Deere 6110L tractor photo
1999 - 2002
6000 TEN Series
Orchard/Vineyard tractor
Series map:
6110L
6210L
84.0hp
90.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6110L Engine
John Deere 4.5L 4-cyl diesel
Fuel tank30.7 gal
116.2 L
Engine details ...
John Deere 6110L Transmissions
12-speed fully synchronized
16-speed power shuttle
16-speed partial power shift
38-speed four-speed power shift
Transmission details ...
John Deere 6110L Power
Engine (gross)84 hp
62.6 kW
PTO (claimed)65 hp
48.5 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic wet disc
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS.
Photos
No photos of the John Deere 6110L are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load sensing
Pressure2900 psi
200.0 bar
Valves1 to 4
Pump flow25.4 gpm
96.1 lpm
 18.9 gpmOptOptional
71.5 lpm
Tractor hitch
Rear TypeII
Controlelectronic lower-link draft sensing
Rear lift4745 lbs
2152 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
 540/1000 (1.375)OptOptional
Dimensions & Tires
Wheelbase94.5 inches
240 cm
Weight7420 to 7916 pounds
Front tire27/9.5-15
2WD Rear tire16.9-24
Full dimensions and tires ...
6110L Serial Numbers
Location:Serial number plate on the right side of the tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery CCA850
 1230 OptOptional
Battery volts12
Battery AH110
 154 OptOptional
References
6110L references literature
6000 TEN Series published in 1998, by John Deere
6000 TEN Series and Advantage Series Tractors published in 1998, by John Deere
6000 TEN Series Tractors and Advantage Series Tractors Product Information Handbook published in 1998, by John Deere
