Tractor Tests | |
OECD 2200: diesel 32-speed 4WD | |
OECD 2197: diesel CVT 4WD | |
OECD 2395: diesel 24-speed 4WD | |
OECD 2420: diesel CVT 4WD |
OCED Tractor Test 2200 | |||
|
OCED Tractor Test 2200 | |
Diesel 32-speed 4WD March 2004 - June 2004, Link: OCED Tractor Test 2200 file | |
PTO performance | |
Power at rated engine speed | 140.7 hp 104.9 kW |
Fuel use | 8.7 gal/hour 32.9 l/hour |
Power at rated PTO speed | 145.2 hp 108.3 kW |
Fuel use | 8.2 gal/hour 31.0 l/hour |
Drawbar performance | |
Max power | 121.5 hp 90.6 kW |
Fuel use | 8.6 gal/hour 32.6 l/hour |
Gear 4TA used for power test. | |
Max pull | 16,455 lbs 7463 kg |
Gear 1TD used for pull test. |
OCED Tractor Test 2197 | |||
|
OCED Tractor Test 2197 | |
Diesel CVT 4WD December 2003 - May 2004, Link: OCED Tractor Test 2197 file | |
PTO performance | |
Max power | 154.4 hp 115.1 kW |
Fuel use | 8.8 gal/hour 33.3 l/hour |
Power at rated engine speed | 143.2 hp 106.8 kW |
Fuel use | 9.4 gal/hour 35.6 l/hour |
Power at rated PTO speed | 153.1 hp 114.2 kW |
Fuel use | 9.1 gal/hour 34.4 l/hour |
Drawbar performance | |
Max power | 115.1 hp 85.8 kW |
Fuel use | 9.3 gal/hour 35.2 l/hour |
Pull at 7.70 KPH | |
Max pull | 16,690 lbs 7570 kg |
Pull at 3.85 KPH |
OCED Tractor Test 2395 | |||
|
OCED Tractor Test 2395 | |
Diesel 24-speed 4WD August 2007 - October 2007, Link: OCED Tractor Test 2395 file | |
PTO performance | |
Power at rated engine speed | 153.8 hp 114.7 kW |
Fuel use | 9.5 gal/hour 36.0 l/hour |
Power at rated PTO speed | 180.4 hp 134.5 kW |
Fuel use | 10.1 gal/hour 38.2 l/hour |
Drawbar performance | |
Max power | 127.7 hp 95.2 kW |
Fuel use | 8.9 gal/hour 33.7 l/hour |
Pull at 10.50 KPH | |
Max pull | 19,920 lbs 9035 kg |
Pull at 2.11 KPH |
OCED Tractor Test 2420 | |||
|
OCED Tractor Test 2420 | |
Diesel CVT 4WD June 2007 - September 2007, Link: OCED Tractor Test 2420 file | |
PTO performance | |
Max power | 179.7 hp 134.0 kW |
Fuel use | 9.7 gal/hour 36.7 l/hour |
Power at rated engine speed | 153.8 hp 114.7 kW |
Fuel use | 9.2 gal/hour 34.8 l/hour |
Power at rated PTO speed | 174.3 hp 130.0 kW |
Fuel use | 9.7 gal/hour 36.7 l/hour |
Drawbar performance | |
Max power | 111.4 hp 83.1 kW |
Fuel use | 8.4 gal/hour 31.8 l/hour |
Pull at 8.21 KPH | |
Max pull | 19,490 lbs 8840 kg |
Pull at 2.45 KPH |
