Tractor Tests | |
OECD 2202: diesel 32-speed 4WD | |
OECD 2198: diesel CVT 4WD | |
OECD 2517: diesel 24-speed 4WD | |
OECD 2421: diesel CVT 4WD |
OCED Tractor Test 2202 | |||
|
OCED Tractor Test 2202 | |
Diesel 32-speed 4WD March 2004 - June 2004, Link: OCED Tractor Test 2202 file | |
PTO performance | |
Max power | 166.0 hp 123.8 kW |
Fuel use | 9.1 gal/hour 34.4 l/hour |
Power at rated engine speed | 156.1 hp 116.4 kW |
Fuel use | 9.6 gal/hour 36.3 l/hour |
Power at rated PTO speed | 165.2 hp 123.2 kW |
Fuel use | 9.2 gal/hour 34.8 l/hour |
Drawbar performance | |
Max power | 135.7 hp 101.2 kW |
Fuel use | 9.9 gal/hour 37.5 l/hour |
Gear 2LA used for power test. | |
Max pull | 16,150 lbs 7325 kg |
Gear 2TB used for pull test. |
OCED Tractor Test 2198 | |||
|
OCED Tractor Test 2198 | |
Diesel CVT 4WD January 2004 - May 2004, Link: OCED Tractor Test 2198 file | |
PTO performance | |
Max power | 168.6 hp 125.7 kW |
Fuel use | 9.5 gal/hour 36.0 l/hour |
Power at rated engine speed | 157.0 hp 117.1 kW |
Fuel use | 10.2 gal/hour 38.6 l/hour |
Power at rated PTO speed | 166.8 hp 124.4 kW |
Fuel use | 10.0 gal/hour 37.9 l/hour |
Drawbar performance | |
Max power | 125.1 hp 93.3 kW |
Fuel use | 10.1 gal/hour 38.2 l/hour |
Pull at 7.52 KPH | |
Max pull | 16,995 lbs 7708 kg |
Pull at 4.33 KPH |
OCED Tractor Test 2517 | |||
|
OCED Tractor Test 2517 | |
Diesel 24-speed 4WD January 2009 - April 2009, Link: OCED Tractor Test 2517 file | |
PTO performance | |
Power at rated engine speed | 165.8 hp 123.6 kW |
Fuel use | 10.1 gal/hour 38.2 l/hour |
Power at rated PTO speed | 196.3 hp 146.4 kW |
Fuel use | 10.5 gal/hour 39.7 l/hour |
Drawbar performance | |
Max power | 136.0 hp 101.4 kW |
Fuel use | 9.5 gal/hour 36.0 l/hour |
Gear 3A used for power test. | |
Max pull | 21,445 lbs 9727 kg |
Gear 1A used for pull test. |
OCED Tractor Test 2421 | |||
|
OCED Tractor Test 2421 | |
Diesel CVT 4WD June 2007 - September 2007, Link: OCED Tractor Test 2421 file | |
PTO performance | |
Max power | 190.0 hp 141.7 kW |
Fuel use | 10.3 gal/hour 39.0 l/hour |
Power at rated engine speed | 162.5 hp 121.2 kW |
Fuel use | 9.7 gal/hour 36.7 l/hour |
Power at rated PTO speed | 185.7 hp 138.5 kW |
Fuel use | 10.2 gal/hour 38.6 l/hour |
Drawbar performance | |
Max power | 118.9 hp 88.7 kW |
Fuel use | 9.3 gal/hour 35.2 l/hour |
Pull at 9.51 KPH | |
Max pull | 19,930 lbs 9040 kg |
Pull at 3.13 KPH |
