New Holland T4040
|
|
| Production | |
| Manufacturer | New Holland |
| Utility tractor | |
| Built in Jesi, Italy | |
| Variants | |
| T4040 | conventional chassis |
| T4040F | narrow chassis |
| T4040V | ultra-narrow chassis |
| Farmall 85C | similar CaseIH model |
| New Holland T4040 Engine | |
| FPT 4.5L 4-cyl diesel | |
| Fuel tank | 21.6 gal 81.8 L |
| 23.2 gal (Deluxe) 87.8 L | |
 Engine details ... | |
| New Holland T4040 Transmissions | |
| 12-speed mechanical shuttle | |
| 16-speed mechanical shuttle | |
| 16-speed power shuttle | |
 Transmission details ... |
| New Holland T4040 Power | |
| Engine (gross) | 84 hp 62.6 kW |
| PTO (claimed) | 70 hp 52.2 kW |
| Drawbar (tested) | 64.0 hp 47.7 kW |
| PTO (tested) | 75.4 hp 56.2 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Platform with ROPS. Cab on deluxe model with heat and air-conditioning. | |
| Photos | |
| No photos of the New Holland T4040 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2,755 psi 190.0 bar |
| Valves | 1 to 5 |
| Pump flow | 16.1 gpm 60.9 lpm |
| Steering flow | 9.4 gpm 35.6 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift (at 24"/610mm) | 3962 lbs 1797 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | 280mm mechanical dry disc |
| Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375)OptOptional | |
| Engine RPM | 540@2196 |
| Dimensions & Tires | |
| Wheelbase | 83.7 inches (4WD) 212 cm |
| 86.0 inches (4WD deluxe) 218 cm | |
| 86.7 inches (2WD) 220 cm | |
| 89.0 inches (2WD deluxe) 226 cm | |
| Weight | 5953 to 6944 pounds |
| Front tire | 11.2R24 |
| Rear tire | 16.9R30 |
 Full dimensions and tires ... | |
| New Holland T4040 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery CCA | 800 |
| Battery volts | 12 |
| References | |
 | |
| T4000 Series Utility Tractors published in 2008, by New Holland |
