New Holland T4020


New Holland T4020 tractor photo
2008 - 2011
T4000 Series
Utility tractor
Series map:
T4020
T4030
64.0hp
76.0hp
Production
ManufacturerNew Holland (a part of CNH)
Utility tractor
Built in Jesi, Italy
Variants
Farmall 65Csimilar CaseIH model
New Holland T4020 Engine
FPT 3.2L 4-cyl diesel
Fuel tank21.6 gal
81.8 L
 19.8 gal (Deluxe)
74.9 L
Engine details ...
New Holland T4020 Transmissions
12-speed mechanical shuttle
16-speed mechanical shuttle
16-speed power shuttle
Transmission details ...
New Holland T4020 Power
Engine (gross)64 hp
47.7 kW
PTO (claimed)50 hp
37.3 kW
Drawbar (tested)50.8 hp
37.9 kW
PTO (tested)58.7 hp
43.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Steeringhydrostatic power
Hydraulic wet disc brakes
Platform with ROPS. Cab on deluxe model with heat and air-conditioning.
Photos
No photos of the New Holland T4020 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2,755 psi
190.0 bar
Valves1 to 5
Pump flow12.8 gpm
48.4 lpm
 16.1 gpmOptOptional
60.9 lpm
Steering flow7.4 gpm
28.0 lpm
 9.4 gpm (with power shuttle)
35.6 lpm
Tractor hitch
Rear TypeII/I
Rear lift (at 24"/610mm)3962 lbs
1797 kg
Power Take-off (PTO)
Rear PTOindependent
Clutch280mm mechanical dry disc
Rear PTO Type540 (1.375)
Engine RPM540@2196
Dimensions & Tires
Wheelbase80.2 inches (4WD)
203 cm
 82.6 inches (4WD deluxe)
209 cm
 83.3 inches (2WD)
211 cm
 85.6 inches (2WD deluxe)
217 cm
Weight5776 to 6768 pounds
Front tire11.2R24
Rear tire16.9R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps85
Battery CCA730
Battery volts12
References
T4020 references literature
T4000 Series Utility Tractors published in 2008, by New Holland
