New Holland T4020 Tests
|
|
| Tractor Tests | |
| OECD 2466: diesel 12-speed 4WD | |
| OECD 2465: diesel 16-speed 4WD |
| OCED Tractor Test 2466 | |||
| |||
| OCED Tractor Test 2466 | |
| Diesel 12-speed 4WD June 2008 - July 2008, Link: OCED Tractor Test 2466 file | |
| PTO performance | |
| Power at rated engine speed | 58.7 hp 43.8 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Power at rated PTO speed | 58.2 hp 43.4 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Drawbar performance | |
| Max power | 50.8 hp 37.9 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Gear 3M used for power test. | |
| Max pull | 6,275 lbs 2846 kg |
| Gear 1M used for pull test. | |
| OCED Tractor Test 2465 | |||
| |||
| OCED Tractor Test 2465 | |
| Diesel 16-speed 4WD May 2008 - July 2008, Link: OCED Tractor Test 2465 file | |
| PTO performance | |
| Power at rated engine speed | 58.7 hp 43.8 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Power at rated PTO speed | 58.3 hp 43.5 kW |
| Fuel use | 3.6 gal/hour 13.6 l/hour |
| Drawbar performance | |
| Max power | 49.9 hp 37.2 kW |
| Fuel use | 3.5 gal/hour 13.2 l/hour |
| Gear 3ML used for power test. | |
| Max pull | 6,995 lbs 3172 kg |
| Gear 1ML used for pull test. | |
