CaseIH Farmall 65C
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Built in Jesi, Italy | |
| Variants | |
| T4020 | similar New Holland model |
| CaseIH Farmall 65C Engine | |
| FPT 3.2L 4-cyl diesel | |
| Fuel tank | 19.8 gal 74.9 L |
 Engine details ... | |
| CaseIH Farmall 65C Transmissions | |
| 16-speed mechanical shuttle | |
| 16-speed power shuttle | |
 Transmission details ... |
| CaseIH Farmall 65C Power | |
| Engine (gross) | 64 hp 47.7 kW |
| PTO (claimed) | 50 hp 37.3 kW |
| Drawbar (tested) | 50.9 hp 38.0 kW |
| PTO (tested) | 59.0 hp 44.0 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Straddle deck platform with ROPS; Cab optional. | |
| Photos | |
| No photos of the CaseIH Farmall 65C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 to 2 |
| Mid valves | 0 to 2 |
| Pump flow | 12.8 gpm 48.4 lpm |
| Total flow | 20.2 gpm 76.5 lpm |
| Steering flow | 7.4 gpm 28.0 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift (at 24"/610mm) | 3960 lbs 1796 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | mechanical dry disc |
| Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375)OptOptional | |
| Engine RPM | 540@2206 |
| Dimensions & Tires | |
| 2WD Wheelbase | 85.6 inches 217 cm |
| 4WD Wheelbase | 82.6 inches 209 cm |
| Weight | 5776 to 6768 pounds |
 Full dimensions and tires ... | |
| CaseIH Farmall 65C attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Charging amps | 120 |
| Battery CCA | 730 |
| Battery volts | 12 |
| References | |
 | |
| Farmall Series Utility Tractors published in 2008, by CaseIH |
