CaseIH Farmall 70
|
|
| Production | |
| Distributor | CaseIH |
| Manufacturer | Turk Tractor |
| Utility tractor | |
| Built in Ankara, Turkey | |
| CaseIH Farmall 70 Engine | |
| FPT 3.2L 4-cyl diesel | |
| Fuel tank | 23.8 gal 90.1 L |
 Engine details ... | |
| CaseIH Farmall 70 Transmissions | |
| 12-speed mechanical shuttle | |
| 20-speed mechanical shuttle with creeper | |
 Transmission details ... |
| CaseIH Farmall 70 Power | |
| Engine (gross) | 65 hp 48.5 kW |
| PTO (claimed) | 52 hp 38.8 kW |
| Drawbar (tested) | 46.2 hp 34.5 kW |
| PTO (tested) | 59.1 hp 44.1 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear lock |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Flat deck platform with ROPS. Cab optional. | |
| Photos | |
| No photos of the CaseIH Farmall 70 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 to 3 |
| Pump flow | 13.6 gpm 51.5 lpm |
| Total flow | 21.7 gpm 82.1 lpm |
| Steering flow | 8.1 gpm 30.7 lpm |
| Tractor hitch | |
| Rear Type | 2 |
| Control | position control and mechanical lower-link draft sensing |
| Rear lift (at 24"/610mm) | 4,010 lbs 1818 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | mechanical dry clutch |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| 2WD Wheelbase | 86 inches 218 cm |
| 4WD Wheelbase | 84 inches 213 cm |
| Weight | 5152 to 6365 pounds |
 Full dimensions and tires ... | |
| CaseIH Farmall 70 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 85 |
| Battery CCA | 800 |
| Battery volts | 12 |
| References | |
 | |
| Farmall Series Utility Tractors published in 2008, by CaseIH |
