John Deere 4025


John Deere 4025 tractor photo
1969 - 1972
Row-Crop tractor
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Monterrey, Mexico
The John Deere model 4025 was an export version of the 4020. The basic units were constructed at Waterloo, and then shipped to Mexico for final assembly and paint.
John Deere 4025 Engine
John Deere 6.6L 6-cyl diesel
Fuel tank34 gal
128.7 L
Engine details ...
John Deere 4025 Transmissions
8-speed partially synchronized
8-speed full power shift
Transmission details ...
John Deere 4025 Power
PTO (claimed)94 hp
70.1 kW
Mechanical
Two-wheel drive
Open operator station.
Hydraulics
Typeopen center
Valves1
Tractor hitch
Rear TypeII/I
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase97.5 inches
247 cm
Weight8555 lbs
3880 kg
Front tire6.00-16
Rear tire15.5-38
Full dimensions and tires ...
4025 Serial Numbers
Location:Serial number plate on the rear of the Deere 4025.
1969211000
1970222143
1971250000
1972260791

FAQ: How to read a serial number table.
References
4025 references literature
Operator's Manual 4025 (OM-R46015) published in 1969
