Mahindra 2815
| | 2006 - 2008 |
| 15 Series | | Compact Utility tractor | | Mitsubishi built |
|
Series map:
2615
2815
3015
26.0hp
28.0hp
30.0hp
| Production |
| Distributor | Mahindra
|
| Manufacturer | Mitsubishi
|
| Compact Utility tractor |
| Original price | $10,660 (2009)
|
| Mahindra 2815 Power |
| Engine | 28 hp
20.9 kW
|
| PTO (claimed) | 22 hp
16.4 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post foldable ROPS. |
| Photos |
| No photos of the Mahindra 2815 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Valves | 0 or 1
|
| Total flow | 7.4 gpm
28.0 lpm
|
| Steering flow | 3.4 gpm
12.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 2,646 lbs
1200 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear PTO Type | 540
|
| Engine RPM | 540@2376
|
| Mid PTO Type | 2000
|
| Engine RPM | 2000@2525
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 46
|
| Battery volts | 12
|
| Battery AH | 55
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on January 26, 2013 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
Attachment details ...
