AGCO DT205B Tests
|
|
| Tractor Tests | |
| OECD 2496: SCR diesel CVT 4WD | |
| OECD 2557: EGR diesel CVT 4WD |
| OCED Tractor Test 2496 | |||
| |||
| OCED Tractor Test 2496 | |
| SCR diesel CVT 4WD October 2008 - February 2009, Link: OCED Tractor Test 2496 file | |
| PTO performance | |
| Max power | 242.3 hp 180.7 kW |
| Fuel use | 12.1 gal/hour 45.8 l/hour |
| Power at rated engine speed | 212.7 hp 158.6 kW |
| Fuel use | 11.6 gal/hour 43.9 l/hour |
| Power at rated PTO speed | 232.9 hp 173.7 kW |
| Fuel use | 12.1 gal/hour 45.8 l/hour |
| Drawbar performance | |
| Max power | 180.1 hp 134.3 kW |
| Fuel use | 11.6 gal/hour 43.9 l/hour |
| Pull at 7.6 KPH | |
| Max pull | 27,890 lbs 12650 kg |
| Pull at 3.9 KPH | |
| OCED Tractor Test 2557 | |||
| |||
| OCED Tractor Test 2557 | |
| EGR diesel CVT 4WD October 2009 - March 2010, Link: OCED Tractor Test 2557 file | |
| PTO performance | |
| Max power | 250.0 hp 186.4 kW |
| Fuel use | 14.0 gal/hour 53.0 l/hour |
| Power at rated engine speed | 216.2 hp 161.2 kW |
| Fuel use | 13.5 gal/hour 51.1 l/hour |
| Power at rated PTO speed | 239.0 hp 178.2 kW |
| Fuel use | 13.8 gal/hour 52.2 l/hour |
| Drawbar performance | |
| Max power | 175.1 hp 130.6 kW |
| Fuel use | 13.5 gal/hour 51.1 l/hour |
| Pull at 7.5 KPH | |
| Max pull | 27,130 lbs 12306 kg |
| Pull at 3.9 KPH | |
