Iseki TX1510


Iseki TX1510 tractor photo
1978 - 1981
Compact Utility tractor
Series map:
TX1410
TX1510
10.3kw
10.9kw
Production
ManufacturerIseki
Compact Utility tractor
Variants
TX1510F4WD
Iseki TX1510 Engine
Mitsubishi 0.8L 3-cyl diesel
Fuel tank3.1 gal
11.7 L
Engine details ...
Iseki TX1510 Power
Engine14.6 hp
10.9 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Tractor hitch
Rear TypeJIS0
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM454@2600
 724@2600
 1185@2600
Dimensions & Tires
Wheelbase50.4 inches
128 cm
Weight1168 to 1213 pounds
Front tire4.00-12
2WD Rear tire8-18
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
TX1510 references literature
Operator's Manual TX1410 - TX1510
TX 1510 published in 1980, by Iseki
