Farmtrac 80


Farmtrac 80 tractor photo
2002 - 2003
Utility tractor
Production
ManufacturerFarmtrac
Utility tractor
Variants
80DT4WD
Farmtrac 80 Engine
Perkins 4.2L 4-cyl diesel
Fuel tank21 gal
79.5 L
Engine details ...
Farmtrac 80 Power
Engine72.4 hp
54.0 kW
PTO (claimed)64.8 hp
48.3 kW
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Wet disc brakes
Open operator station.
Photos
No photos of the Farmtrac 80 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2490 psi
171.7 bar
Valves1 or 2
Pump flow11 gpm
41.6 lpm
Tractor hitch
Rear TypeII
Rear lift (at ends)5300 lbs
2404 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2115
Dimensions & Tires
2WD Wheelbase93 inches
236 cm
4WD Wheelbase91 inches
231 cm
Weight5675 lbs
2574 kg
Front tire7.50-16
2WD Rear tire16.9-30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery volts12
Battery AH88
