J.I. Case 4894 Transmission


J.I. Case 4894 tractor photo
1983 - 1984
4WD 94 Series
Four-wheel Drive (4WD) tractor
Series map:
4694
4894
4994
261.0hp
300.0hp
400.0hp
Transmission
Transmissionpartial power shift
Gears12 forward and 4 reverse
Clutchhydraulic wet disc
Four ranges (1-4) with three power shift gears (1-3) plus reverse in each range. Both shift levers mounted on the dashboard. Range shift lever is to the left in a H-pattern. Gear shift is an inline pattern on the right.
Speeds
With 23.1x30 tires.
4894 partial power shift  speeds
Shift Pattern
J.I. Case 4894 transmission controls
