Ford 8670


Ford 8670 tractor photo
1993 - 2002
70 Genesis Series
Row-Crop tractor
Series map:
8670
8770
170.0hp
190.0hp
Production
ManufacturerFord
Row-Crop tractor
Built in Winnipeg, Manitoba, Canada
Original price was $84,500 in 2000
Variants
2145similar Buhler Versatile model
Ford 8670 Engine
Ford 7.5L 6-cyl diesel
Engine details ...
Ford 8670 Transmissions
16-speed full power shift
32-speed creeper
Transmission details ...
Ford 8670 Power
Engine170 hp
126.8 kW
PTO (claimed)145 hp
108.1 kW
Drawbar (tested)132.1 hp
98.5 kW
PTO (tested)167.6 hp
125.0 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Cab standard with air-conditioning.
Capacity
Fuel110 gal
416.4 L
Hydraulic system30.9 gal
117.0 L
Front hubs1.7 qts (each)
1.6 L
Front diff.13 qts
12.3 L
Hydraulics
Typeclosed center load sensing
Capacity30.9 gal
117.0 L
Pressure2750 psi
189.6 bar
Valves3
Pump flow24 gpm
90.8 lpm
Total flow31 gpm
117.3 lpm
 55 gpm (MegaFlow optional)
208.2 lpm
Tractor hitch
Rear TypeIII
Rear lift10000 lbs
4536 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1878
 1000@1903
Dimensions & Tires
Wheelbase118.3 inches
300 cm
 122.6 inches (SuperSteer)
311 cm
Weight15800 to 18200 pounds
Front tire14L-16.1
Rear tire18.4R42
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps130
Batteries2
Battery CCA950
Battery volts12
References
8670 references literature
Front-end Loaders published in 1995, by New Holland
New for '94 - Genesis 70 Series Tractors published in 1993, by Ford
145 to 210 PTO hp GENESIS 70 Series Tractors published in 1993, by Ford
Serie 70 170 - 240 hp Tractors published in 1994, by Ford
