Ford 6610 Tests
|
|
| Tractor Tests | |
| NTTL 1430: diesel 16x4 4WD | |
| NTTL 1431: diesel 16x8 2WD |
| Nebraska Tractor Test 1430 | |||
| |||
| Nebraska Tractor Test 1430 | |
| Diesel 16x4 4WD April 1 - 21, 1982 Link: Nebraska Tractor Test 1430 file | |
| PTO performance | |
| Power at rated engine speed | 72.13 hp 53.8 kW |
| Fuel use | 4.7 gal/hour 17.8 l/hour |
| Power at rated PTO speed | 68.27 hp 50.9 kW |
| Fuel use | 4.4 gal/hour 16.7 l/hour |
| Drawbar performance | |
| Max power | 60.96 hp 45.5 kW |
| Fuel use | 4.5 gal/hour 17.0 l/hour |
| Gear 6L used for power test. | |
| Max pull | 7,887 lbs 3577 kg |
| Gear 3L used for pull test. | |
| Nebraska Tractor Test 1431 | |||
| |||
| Nebraska Tractor Test 1431 | |
| Diesel 16x8 2WD April 13 - May 4, 1982 Link: Nebraska Tractor Test 1431 file | |
| PTO performance | |
| Power at rated engine speed | 72.30 hp 53.9 kW |
| Fuel use | 4.8 gal/hour 18.2 l/hour |
| Power at rated PTO speed | 15.43 hp 11.5 kW |
| Fuel use | 1.0 gal/hour 3.8 l/hour |
| Drawbar performance | |
| Max power | 61.37 hp 45.8 kW |
| Fuel use | 4.7 gal/hour 17.8 l/hour |
| Gear 6L used for power test. | |
| Max pull | 7,948 lbs 3605 kg |
| Gear 3L used for pull test. | |
