Ford 1910 Transmission


Ford 1910 tractor photo
1983 - 1986
Ten Compact Series
Compact Utility tractor
Shibaura built
Series map:
1710
1910
2110
26.0hp
32.0hp
38.0hp
Transmission options
12-speed unsynchronized gear
12-speed partially synchronized
Transmission
Typeunsynchronized gear
Gears12 forward and 4 reverse
Clutch239mm dry disc
Oil capacity29.6 qts
28.0 L
Three gears, plus reverse, in four ranges.
Speeds
With 13.6-24 rear tires.
1910  unsynchronized gear speeds
Transmission
Typepartially synchronized
Gears12 forward and 4 reverse
Speeds
1910  partially synchronized speeds
