Tractors > John Deere > 8295RT

John Deere 8295RT



John Deere 8295RT tractor photo
2009 - 2010
Agricultural Crawler tractor
Series map:
8295RT
8320RT
295.0hp
320.0hp
Production
ManufacturerJohn Deere
Agricultural Crawler tractor
Built in Waterloo, Iowa, USA
Variants
8295Rwheeled tractor
John Deere 8295RT Engine
John Deere 9.0L 6-cyl diesel
Engine details ...
John Deere 8295RT Transmission
16-speed full power shift
Transmission details ...
John Deere 8295RT Power
Engine (gross)295 hp
220.0 kW
Engine (net)284 hp
211.8 kW
Engine (max)322 hp
240.1 kW
PTO (claimed)235 hp
175.2 kW
Drawbar (tested)212.62 hp
158.6 kW
PTO (tested)279.14 hp
208.2 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringelectro-hydraulic power
Hydraulic wet disc brakes
CommandView cab standard with heat and air-conditioning. Optional automatic temperature control, mirros, and front/rear windshield wipers.
Photos
No photos of the John Deere 8295RT are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel200 gal
757.0 L
Hydraulic system68.3 gal
258.5 L
Hydraulics
Typeclosed center pressure-flow compensated
Capacity68.3 gal
258.5 L
Pressure2900 psi
200.0 bar
Valves3 to 5
Pump flow35 gpm
132.5 lpm
Total flow44 gpm
166.5 lpm
 60 gpm (optional)
227.1 lpm
Tractor hitch
Rear TypeIII/IIIN
 IVN/III
Rear lift (at 24"/610mm)16,800 lbs
7620 kg
 19,300 lbs (optional)
8754 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1-3/4)
Dimensions & Tracks
Wheelbase99 inches
251 cm
Weight34,460 lbs
15631 kg
25-inch tracks
Full dimensions and tracks ...
8295RT Serial Numbers
Location:Right side of tractor.
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery CCA925
Battery volts12
References
8295RT references literature
8R/8RT Series published in 2009, by John Deere
8R/8RT Series - Top 10 Feature & Benefits, plus Tractor Optimization Tips published in 2009, by John Deere
