John Deere 4075R


John Deere 4075R tractor photo
2024 -
4R Series
Compact Utility tractor
Series map:
4066R
4075R
65.0hp
74.3hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
Original price was $68,049 in 2024
John Deere 4075R Engine
Yanmar 2.1L 4-cyl diesel
Fuel tank14.7 gal
55.6 L
Engine details ...
John Deere 4075R Power
Engine (gross)74.3 hp
55.4 kW
PTO (claimed)60 hp
44.7 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockmechanical rear
Power steering
Wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the John Deere 4075R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves3 to 5
Total flow15.9 gpm
60.2 lpm
Tractor hitch
Rear TypeII/I
Controlposition control
Rear lift (at ends)3130 lbs
1419 kg
Rear lift (at 24"/610mm)2500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540 (1.375)
Engine RPM540@2600
 540E@1750
Dimensions & Tires
Wheelbase73 inches
185 cm
Weight4828 lbs
2189 kg
Front tire8-16
Rear tire13.6-28
Full dimensions and tires ...
4075R Serial Number Location
John Deere 4075R serial number location
Serial number plate on the right side of the 4075R tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps75
Battery CCA770
Battery volts12
References
4075R references literature
4 Series published in 2023, by John Deere
Operator's Manual 4 Series (OMTR130411) published in 2023*
*Publication contains known errors.
