J.I. Case 310D
|
|
| Production | |
| Manufacturer | J.I. Case |
| Agricultural Crawler tractor | |
| Total built | 1703 |
| Variants | |
| 310D CL | crawler loader |
| J.I. Case 310D Engine | |
| J.I. Case 2.4L 4-cyl gasoline | |
 Engine details ... |
| J.I. Case 310D Transmission | |
| 3-speed gear | |
 Transmission details ... |
| J.I. Case 310D Power | |
| Engine (gross) | 42 hp 31.3 kW |
| Mechanical | |
| Drive | crawler |
| Open operator station. | |
| Photos | |
| No photos of the J.I. Case 310D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 10 gal 37.9 L |
| Hydraulic system | 9 gal 34.1 L |
| Hydraulics | |
| Type | open center |
| Capacity | 9 gal 34.1 L |
| Pump flow | 15 gpm 56.8 lpm |
| Tractor hitch | |
| Rear Type | I OptOptional |
| Rear lift | 700 lbs 317 kg |
| Dimensions & Tracks | |
| Weight | 5375 lbs 2438 kg |
| 11-inch tracks | |
 Full dimensions and tracks ... | |
| 310D Serial Numbers | |
| 1960 | 3012301 |
FAQ: How to read a serial number table. | |
| References | |
 | |
| 310D Angling Dozer published in 1960, by J.I. Case | |
| 310D Drawbar Tractor published in 1960, by J.I. Case | |
| 310D Bulldozer published in 1960, by J.I. Case |
