Tractors > John Deere > 5045D

John Deere 5045D



John Deere 5045D tractor photo
2008 - 2014
5D Series
Utility tractor
Series map:
5045D
5055D
45.0hp
55.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Pune, Maharashtra, India
Original price was $17,233 in 2014
Variants
5045D2WD Economy
5045E4WD Mid-spec
John Deere 5045D Engine
John Deere 2.9L 3-cyl diesel
Fuel tank16 gal
60.6 L
Engine details ...
John Deere 5045D Transmission
8-speed
Transmission details ...
John Deere 5045D Power
Engine (gross)45 hp
33.6 kW
PTO (claimed)37 hp
27.6 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Differential lockrear diff lock standard
Steeringhydrostatic power
Mechanical wet disc brakes
Folding 2-post ROPS
Photos
No photos of the John Deere 5045D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2828 psi
195.0 bar
Rear valves1 or 2
Mid valves2 (optional)
Pump flow10.9 gpm
41.3 lpm
Total flow17.4 gpm
65.9 lpm
Steering flow6.5 gpm
24.6 lpm
Steering press.1958 psi
135.0 bar
Tractor hitch
Rear Type2
Controlposition and top-link draft control
Rear lift (at 24"/610mm)2,810 lbs
1274 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchmechanical
Rear PTO Type540
Dimensions & Tires
Wheelbase76.8 inches
195 cm
Weight4,189 lbs
1900 kg
Front tire7.5-16
Rear tire13.6-28
Full dimensions and tires ...
John Deere 5045D attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA623
Battery volts12
References
5045D references literature
New 5 Series Utility Tractors published in 2009, by John Deere
5 Series published in 2009, by John Deere
5D - 5E - 5E Limited Tractors published in 2012, by John Deere
5D - 5E Utility Tractors published in 2013, by John Deere*
5D - 5E Utility Tractors published in 2014, by John Deere*
*Publication contains known errors.
