John Deere 6900



John Deere 6900 tractor photo
1994 - 1997
6000 Series
Row-Crop tractor
Series map:
6800
6900
89.5kw
96.9kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6900 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank66.1 gal
250.2 L
Engine details ...
John Deere 6900 Transmissions
16-speed partial power shift
20-speed partial power shift
Transmission details ...
John Deere 6900 Power
Engine130 hp
96.9 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic
Power steering
Wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the John Deere 6900 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Pressure2900 psi
200.0 bar
Pump flow15.9 gpm
60.2 lpm
 25.4 gpmOptOptional
96.1 lpm
Tractor hitch
Rear TypeII/IIIN
Rear lift15082 lbs
6841 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540E/1000
Engine RPM540E@1754
 1000@2000
Front PTOindependent
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Weight11,885 lbs
5391 kg
Front tire16.9R28
Rear tire20.8R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps85
 120 OptOptional
Battery volts12
References
6900 references literature
6-Cylindriga Traktorer I 6000-Serien published in 1995, by John Deere
Trattoti 6 Cilindri Serie 6000 published in 1996, by John Deere
