Kubota MX4700 Transmission


Kubota MX4700 tractor photo
2009 - 2014
MX Series
Utility tractor
Series map:
MX4700
MX5100
48.2hp
52.2hp
Transmission options
8-speed partially synchronized
hydrostatic
Transmission
TransmissionSynchro Shuttle
Typepartially synchronized
Gears8 forward and reverse
Clutchdry disc
Oil capacity46.4 qts
43.9 L
Transmission is synchronized between gears 3-4 and shuttle shifting.
Speeds
With 14.9-26 R1 rear tires.
MX4700  partially synchronized speeds
Transmission
Typehydrostatic
Gearsinfinite forward and reverse (3-range)
Hydrostatic transmission with three ranges and treadle foot pedal. Cruise control standard.
Speeds
With 14.9-26 R1 rear tires.
MX4700  hydrostatic speeds
