Tractors > John Deere > 6605

John Deere 6605



John Deere 6605 tractor photo
1998 - 2002
Advantage Series
Utility tractor
Series map:
6405
6605
7405
94.4hp*
105.6hp*
116.7hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $36,900 in 1999
John Deere 6605 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank54.7 gal
207.0 L
Engine details ...
John Deere 6605 Transmissions
12-speed fully synchronized
16-speed power shuttle
Transmission details ...
John Deere 6605 Power
PTO (claimed)95 hp
70.8 kW
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post folding ROPS. Advantage Cab optional with air-conditioning.
Photos
No photos of the John Deere 6605 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
TypeHydraVantage constant flow load sensing
Pressure2500 psi
172.4 bar
Valves1
Total flow17.5 gpm
66.2 lpm
Tractor hitch
Rear TypeII
Controlposition control with optional draft control
Rear lift5915 lbs
2683 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540@2143
 1000@2208
Dimensions & Tires
2WD Wheelbase104.3 inches
264 cm
4WD Wheelbase106.3 inches
270 cm
Weight8776 to 10252 pounds
Front tire10.00-16
Rear tire18.4-38 (2WD)
Full dimensions and tires ...
6605 Serial Numbers
1998206500
1999233000
2000261400
2002322111

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery CCA1230
Battery volts12
Battery AH154
References
6605 references literature
6000 Series Tractors and Advantage Series Tractors Product Information Handbook published in 1997, by John Deere
6000 TEN Series and Advantage Series Tractors published in 1998, by John Deere
6000 TEN Series Tractors and Advantage Series Tractors Product Information Handbook published in 1998, by John Deere
