Tractors > CaseIH > Magnum 335

CaseIH Magnum 335 Tests



CaseIH Magnum 335 tractor photo
2008 - 2011
Magnum Series
Row-Crop tractor
Series map:
Magnum 305
Magnum 335
304.0hp
330.0hp
OCED Tractor Test 1936
Magnum 335 fuel use from test 611
OCED Tractor Test 1936
Diesel 19-speed 4WD
September 17 - 26, 2008
Link: OCED Tractor Test 1936 file
PTO performance
Max power314.96 hp
234.9 kW
Fuel use18.5 gal/hour
70.0 l/hour
Power at rated engine speed277.67 hp
207.1 kW
Fuel use16.9 gal/hour
64.0 l/hour
Power at rated PTO speed305.50 hp
227.8 kW
Fuel use17.1 gal/hour
64.7 l/hour
Drawbar performance
Max power243.25 hp
181.4 kW
Fuel use16.8 gal/hour
63.6 l/hour
Gear 7 used for power test.
Max pull38,024 lbs
17247 kg
Gear 2 used for pull test.
