CaseIH JX80U Transmission


CaseIH JX80U tractor photo
2002 - 2003
JXU Maxxima Series
Utility tractor
Series map:
JX80U
JX90U
74.0hp
84.0hp
Transmission options
24-speed two-speed power shift
24-speed power shuttle
20-speed syncromesh
Transmission
Typetwo-speed power shift
Gears24 forward and 12 reverse
Two-speed power shift with left-hand synchronized shuttle.
Speeds
JX80U  two-speed power shift speeds
Transmission
Typepower shuttle
Gears24 forward and reverse
Four gears (1-4) in three ranges (I, II, III) with push-button power shift and power shuttle
Transmission
Typesyncromesh
Gears20 forward and 12 reverse
