John Deere 4730



John Deere 4730 tractor photo
1977 - 1981
Row-Crop tractor
Series map:
4530
4730
4930
85.0kw
87.2kw
119.3kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
The John Deere 4730 was the same as the model 4240, exported to Argentina from the United States.
John Deere 4730 Engine
John Deere 7.6L 6-cyl diesel
Fuel tank46 gal
174.1 L
Engine details ...
John Deere 4730 Transmissions
8-speed partially synchronized
16-speed partial power shift
8-speed full power shift
Transmission details ...
John Deere 4730 Power
Engine117 hp
87.2 kW
PTO (claimed)110 hp
82.0 kW
Mechanical
Two-wheel drive
Power steering
Sound Gard cab with air-conditioning optional.
Photos
No photos of the John Deere 4730 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Dimensions & Tires
Wheelbase105.7 inches
268 cm
Weight10900 lbs
4944 kg
Front tire10.00-16
Rear tire18.4-38
Full dimensions and tires ...
4730 Serial Numbers
Location:Serial number plate on the rear of the 4730, above the PTO.
Electrical
Groundnegative
Charging systemalternator
Charging amps61 (open)
 72 (cab)
Batteries2
Battery volts6
Battery Group5D
References
4730 references literature
John Deere 4430 Tractor (OM-R65532 A7) published in 1976
