Tractors > John Deere > 3530

John Deere 3530



John Deere 3530 tractor photo
1975 - 1980
Row-Crop tractor
Series map:
3330
3530
4530
58.6kw
78.3kw
85.0kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Rosario, Argentina
John Deere 3530 Engine
John Deere 5.4L 6-cyl diesel
Engine details ...
John Deere 3530 Transmission
8-speed
Transmission details ...
John Deere 3530 Power
Engine105 hp
78.3 kW
PTO (claimed)91.9 hp
68.5 kW
Mechanical
Two-wheel drive
Power steering
Open operator station.
Photos
No photos of the John Deere 3530 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel38.3 gal
145.0 L
Hydraulic system12.9 gal
48.8 L
Hydraulics
Typeclosed center
Capacity12.9 gal
48.8 L
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic
Rear PTO Type540
Dimensions & Tires
Wheelbase103.5 inches
262 cm
Weight12070 lbs
5474 kg
Front tire7.50x16
Rear tire18.4x34
Full dimensions and tires ...
Electrical
Charging systemalternator
Charging amps28
Battery volts12
Battery AH110
References
3530 references literature
Tractor 3530 published in 1979, by John Deere
